The 3P4MH 3A Thyristor is P-gate fully diffused mold SCRs with an average on-current of 3 A. The repeat peak off-voltages and reverse voltages are 400 V and 600 v.
3P4M Pinout
3P4M Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Cathode |
| 2 | Anode |
| 3 | Gate |
3P4MH Key Features
- A small and lightweight package TO-202A
- Easy to handle even on the mounting surface due to its TO-202A dimensions
- Processing of lead wires and heatsink (tablet) using jigs is also possible.
- Employs flame-retardant epoxy resin (UL94V-0)
3P4MH Specification
| Type | Vdsm (V) | Vrsm (V) | It (A) | Igt (mA) | Vgt (V) |
|---|---|---|---|---|---|
| 3P4MH | 500 | 500 | 3.0 | 0.2 | 0.8 |
Application
- Noncontact switches of consumer electronic equipment
- Electric equipment
- Audio equipment
- Light industry equipement
You can download this datasheet for 3P4MH 3A 400V Thyristor – Datasheet from the link given below:
