The 2SC945 NPN General Purpose Transistor is an audio frequency amplifier high-frequency OSC NPN transistor.
2SC945 Pinout
2SC945 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2SC945 Key Features
- Collector-Emitter voltage: BVCBO=50V
- Collector current up to 150mA
- High hFE linearity
- Complimentary to UTC 2SA733
2SC945 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 40 V |
| Collector-Base Voltage (Vcb) | 50 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.1 A |
| Collector Power Dissipation (Pc) | 0.25 W |
| Transition Frequency | 125 MHz |
Application
- Audio frequency amplifier high-frequency OSC NPN transistor.
You can download this datasheet for 2SC945 NPN General Purpose Transistor – Datasheet from the link given below:
