2SC1959 PNP Audio Frequency Amplifier is designed for driver stage and switching applications. 2SC1959 is Complementary to 2SA562TM.
2SC1959 Pinout
2SC1959 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2SC1959 Key Features
- Excellent hyg Linearity
- hFE (2)=25 (Min.): VCE =6V, Iç=400mA
- 1 Watt Amplifier Applications,
- Complementary to 2SA562TM.
2SC1959 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 30 V |
| Collector-Base Voltage (Vcb) | 35 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.5 A |
| Collector Power Dissipation (Pc) | 0.5 W |
| Transition Frequency | 50 MHz |
Application
- Audio Frequency LOW Power Amplifier Application
- Driver Stage Amplifier Application
- Switching Application
You can download this datasheet for 2SC1959 PNP Audio Frequency Amplifier – Datasheet from the link given below:
