2SA1316 PNP General Purpose Transistor is designed for low noise audio amplifier applications. 2SA1316 is complementary to 2Sc3329.
2SA1316 Pinout
2SA1316 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2SA1316 Key Features
- Very low noise in the region of low signal source impedance equivalent input noise voltage: En = 0.6 nV/Hz1/2 (typ.)
- Low pulse noise. Low 1/f noise
- Low base spreading resistance: rbb’ = 2.0 Ω (typ.)
2SA1316 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 80 V |
| Collector-Base Voltage (Vcb) | 80 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.1 A |
| Collector Power Dissipation (Pc) | 0.4 W |
| Transition Frequency | 50 MHz |
Applicationr
- Low Noise Audio Amplifier Applications
You can download this datasheet for 2SA1316 PNP General Purpose Transistor – Datasheet from the link given below:
