2N6344 8A 600V TRIAC – Datasheet

2N6344 TRIAC is the primary design for full‐wave AC control applications such as light dimmers, motor controls, heating controls, and power supplies or wherever full‐wave silicon gate controlled solid‐state devices are needed. Triac type thyristors switch from a blocking to a conducting state for either polarity of applied anode voltage with positive or negative gate triggering.

2N6344 Pinout

2N6344 Pin Configuration

Pin No	Pin Name
1	Cathode
2	Anode
3	Gate

2N6344 Key Features

• Blocking Voltage to 800 Volts
• All Diffused and Glass Passivated Junctions for Greater Parameter Uniformity and Stability
• Small, Rugged, Thermowatt Construction for Low Thermal Resistance, High Heat Dissipation and Durability
• Gate Triggering Guaranteed in all Four Quadrants
• For 400 Hz Operation, Consult Factory
• Device Marking: Logo, Device Type

2N6344 Specification

Type	Vdsm (V)	It (A)	Igt (mA)	Vgt (V)
2N6344	600	8.0	35	1.1

Application

• It is used for a wide range of switching applications
• Light dimmers
• Motor controls
• Heating controls
• Power supplies

You can download this datasheet for 2N6344 8A 600V TRIAC – Datasheet from the link given below:
