The 2N5172 NPN General Purpose Transistor is designed for use as general-purpose amplifiers and switches requiring collector currents to 300 mA.
2N5172 Pinout
2N5172 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2N5172 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 25 V |
| Collector-Base Voltage (Vcb) | 25 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.1 A |
| Collector Power Dissipation (Pc) | 0.2 W |
| Transition Frequency | 200 MHz |
Application
- General-Purpose amplifiers and Switches
You can download this datasheet for 2N5172 NPN General Purpose Transistor – Datasheet from the link given below:
