The 2N4920 is silicon PNP Epitaxial Base Power Transistor designed for Medium power amplifier and switching applications.
What is Power Transistor?
Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.
2N4920 Pinout
2N4920 Pin Configuration
Pin No | Pin Name |
---|---|
1 | Emitter |
2 | Collector |
3 | Base |
2N4920 Key Features
- Low Saturation Voltage —
- VCE(sat) = 0.6 Vdc (Max) @ IC = 1.0 Amp
- Excellent Power Dissipation Due to Thermopad Construction
- PD = 30 W @ TC = 25C
- Excellent Safe Operating Area
- Gain Specified to IC = 1.0 Amp
Specification
Ic (mA) | Pd (mW) | Vce (max) | Vcb | hfe | @ Ic | FT (MHz) |
---|---|---|---|---|---|---|
1 | 30 | 80 | 80 | 30-150 | 500 | 3.0 |
2N4920 Equivalent/Alternate:
- 2N40, 2N400, 2N4000, 2N4001, 2N4002, 2N4923
Application
- Driver Circuits
- Switching Amplifier
You can download this datasheet for 2N4920 PNP Power Transistor from the link given below:
