The CENTRAL SEMICONDUCTOR 2N3563 is a Silicon NPN Small Signal Transistor designed for general purpose amplifier applications.
2N3563 Pinout
2N3563 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
2N3563 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 12 V |
| Collector-Base Voltage (Vcb) | 30 V |
| Emitter-Base Voltage (Veb) | 4 V |
| Collector Current (Ic) | 0.05 A |
| Collector Power Dissipation (Pc) | 0.2 W |
| Transition Frequency | 600 MHz |
Application
- General purpose amplifier applications
You can download this datasheet for 2N3563 NPN RF/IF Oscillator – Datasheet from the link given below:
