2N3392 NPN General Purpose Amplifier – Datasheet

This device is designed for use as general-purpose amplifiers and switches requiring collector currents to 300 mA.

2N3392 Pinout

2N3392 Pin Configuration

Pin No	Pin Name
1	Emitter
2	Collector
3	Base

2N3392 Specification

Name	Description
Collector-Emitter Voltage (Vce)	25 V
Collector-Base Voltage (Vcb)	25 V
Emitter-Base Voltage (Veb)	5 V
Collector Current (Ic)	0.1 A
Collector Power Dissipation (Pc)	0.2 W
Transition Frequency	70 MHz
