The 2N1613 is a silicon planar epitaxial NPN transistor in the Jedec TO-39 metal case. It is designed for use in high-performance amplifiers, oscillators, and switching circuits. The 2N1711 is also used to advantage in amplifiers where low noise is an important factor.
2N1613 Pinout
2N1613 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
2N1613 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage | 50 V |
| Collector-Base Voltage | 75 V |
| Emitter-Base Voltage | 7 V |
| Collector Current | 0.5 A |
| Collector Dissipation | 0.8 W |
| DC Current Gain (hfe) | 40 to 120 |
| Transition Frequency | 60 MHz |
You can download this datasheet for 2N1613 NPN General Purpose Transistor – Datasheet from the link given below:
