The M27C16 is a 16,384 bit UV erasable and electrically programmable memory EPROM, ideally suited for applications where fast turn-around and pattern experimentation are important requirements. The M27C16 is housed in a 24 pin Window Ceramic Frit-Seal Dual-in-Line package. The transparent lid allows the user to expose the chip to ultraviolet light to erase the bit pattern. A new pattern can then be written to the device by following the programming procedure.
27C16 Pinout
27C16 Pin Configuration
Pin Number | Pin No | Description |
---|---|---|
1 | A7 | Address Input |
2 | A6 | Address Input |
3 | A5 | Address Input |
4 | A4 | Address Input |
5 | A3 | Address Input |
6 | A2 | Address Input |
7 | A1 | Address Input |
8 | A0 | Address Input |
9 | Q0 | Data Output |
10 | Q1 | Data Output |
11 | Q2 | Data Output |
12 | Vss | Ground |
13 | Q3 | Data Output |
14 | Q4 | Data Output |
15 | Q5 | Data Output |
16 | Q6 | Data Output |
17 | Q7 | Data Output |
18 | Ep’ | Chip Enable |
19 | A10 | Address Input |
20 | G’ | Output Enable |
21 | Vpp | Program Supply |
22 | A9 | Address Input |
23 | A8 | Address Input |
24 | Vcc | Positive Power Supply |
27C16 Key Features
- Access Time:
- M2716-1 is 350ns
- M2716 is 450ns
- Single 5V supply voltage
- Static-No Clocks Required
- Inputs and Outputs TTL Compatible
- During Both Read and Program Modes
- Three state output with tide-OR-capability
- Extended temperature range
- Programming Voltage: 25V
You can download this datasheet for 27C16 16K 150ns CMOS EPROM – Datasheet from the link given below:
