1N5391 50V 1.5A General Purpose Diode – Datasheet

1,577 views

1N5391 is a 50 Volt 1.5 Ampere Silicon Rectifier General Purpose Diode and its voltage range is up to 50 to 1000 Volts. 1N5391 has a high surge current capability.

1N5391 Features

  • Low forward voltage drop
  • High current capability
  • High reliability
  • High surge current capability

1N5391 Specification

Mfr Package DescriptionDO-15, 2 PIN
Diode TypeRECTIFIER DIODE
Diode Element MaterialSILICON
Forward Voltage-Max (VF)1.0  V
Non-rep Pk Forward Current-Max55.0  A
Operating Temperature-Max175.0  Cel
Output Current-Max1.5  A
Peak Reflow Temperature (Cel)260
Rep Pk Reverse Voltage-Max50.0  V

You can download this datasheet for 1N5391 50V 1.5A General Purpose Diode from the link given below:
