1N5239 9.1V 500mW Zener Diode – Datasheet

2,232 views

1N5239 9.1 Volt 500mW Zener diode is a two-way switch means that it can conduct current in forward as well as reverse direction. It is a heavily doped diode and permits the reverse current when a specific voltage level is reached.

1N5239 Features & Specification

  • Nominal Zener Voltage (Vz): 9.1V
  • Max. Regulator Current (Izm): 0.050A
  • Max. Reverse Leakage Current (Ir): 3µA
  • Forward Voltage Drop (Vf): 1.1V
  • Total Power Dissipation (Ptot): 500mW

You can download this datasheet for 1N5239 9.1V 500mW Zener Diode from the link given below:
