1N4150 75V 200mA Ultra Fast Recovery Diode – Datasheet

1,836 views

The 1N4150 is a high-speed switching diode fabricated in planar technology, and encapsulated in hermetically sealed leaded glass SOD27 (DO-35) packages.

1N4150 Features & Specification

  • Peak Repeat. Reverse Voltage (Vrrm): 75V
  • Continuous Reverse Voltage (Vr): 50V
  • Continuous Forward Current (If): 0.3A
  • Max. Reverse Current (Ir): 100nA
  • Max. Forward Voltage Drop (Vf): 1.0V
  • Total Power Dissipation (Ptot): 500mW
  • Reverse Recovery Time (Trr): 6.0nS

Application

  • High-speed switching
  • General purpose use in computer and industrial applications

You can download this datasheet for 1N4150 75V 200mA Ultra Fast Recovery Diode from the link given below:
