The 1N4148 is high-speed switching diodes fabricated in planar technology, and encapsulated in hermetically sealed leaded glass SOD27 (DO-35) packages.
1N4148 Features
- Hermetically sealed leaded glass SOD27 (DO-35) package
- High switching speed: max. 4 ns
- General application
- Continuous reverse voltage: max. 75 V
- Repetitive peak reverse voltage: max. 75 V
- Repetitive peak forward current: max. 450 mA.
1N4148 Specification
| Mfr Package Description | HERMETIC SEALED, GLASS PACKAGE-2 |
| Diode Type | RECTIFIER DIODE |
| Diode Element Material | SILICON |
| Forward Voltage-Max (VF) | 1.0 V |
| Non-rep Pk Forward Current-Max | 0.5 A |
| Operating Temperature-Min | -65.0 Cel |
| Operating Temperature-Max | 175.0 Cel |
| Output Current-Max | 0.2 A |
| Power Dissipation-Max | 0.5 W |
| Rep Pk Reverse Voltage-Max | 100.0 V |
| Reverse Current-Max | 0.5 µA |
| Reverse Recovery Time-Max | 0.004 µs |
Application
- High-speed switching.
You can download this datasheet for 1N4148 100V 200mA General Purpose Diode from the link given below:
